TECH SPECS
VEHICLE
Vehicle Dimensions

Wheelbase

Seat Heigh

Min. Ground Clearance

Net Weight

Max Load

Braking

Braking Efficiency

Rim Size

Tire size (CST)

Tire size (Maxxis)

Fork

Rear Shock

Min. Turning Radius

Steering Angle

Forward Tilt Angle

2,200 x 810 x 1,220mm (86 x 32 x 48 in)

1380mm (52.3 in)

910mm (35.8 in)

315mm (12.40 in)

98kg (216 lbs)

160kg (353 lbs)

Hydraulic Disc

3.64 / 3.09 (m/s2)

1.6×21 / 2.15×18

70/100-21 – 90/100-18

80/100-21 – 110/90-18

Dual Chamber 850mm, 43 tube / Travel 250mm

350mm travel / 90mm / 500-720 lbs spring

2.1 (m)

>45°

26°

POWER
Nominal Voltage

Maximum Speed

Peak Torque

Peak Power

Range (25 km/h)

Power Mode

DC 97.2V

Factory limited to 32 km/h (20 mph)

754 Nm

32 Kw

115 km (71.5 miles)

Eco / Sport / Hyper / Reverse

ELECTRONIC
Battery Pack

Battery Cells

Battery weight

Battery Protection Level

Regenerative Braking

Display

97.2V 45AH

Samsung 50S 21700 / LG H51

24.5 kg (58 lbs)

IP67

4-level adjustment

TFT 320 DPI / 167° angle

MOTOR
Motor type

Mounting Position

Motor Cooling

Motor Rated Torque

Motor Peak Torque

Motor Rated Power

DC Permanent Magnet Synchronous

Mid-mounted

Air-cooled

>14 n.m

>90 n.m

8.6 Kw

TRANSMISSION
Primary Transmission

Drive Transmission

Front Sprocket

Rear Sprocket

Gearbox

520 Chain

14/15T

50/53T
